Core Size EPC 17

Description

GENERAL INFORMATION ::

The core has a distinct “E” shape with flat surfaces, allowing for easy winding of coils and efficient magnetic flux path. The industry standard flat design of EPC cores offers excellent space utilization for transformers and inductors. The optimized cross-sectional area is ideal for very flat compact transformer applications.

TYPICAL CHARATERSTICS ::

• Magnetics Shielding                 :     External magnetic field generated close to exposed winding
• Cost of Core                                :     Low
• Cost of Winding & Assembly  :     Low
• Heat Dissipation                        :     Very Good
• Uniform Cross Section             :     Yes

APPLICATIONS ::

• Switch Mode Power Supplies (SMPS)
• Pulse Transformers
• Differential Mode Inductors
• PFC
